Reference image. Final construction follows the confirmed model and quotation.
Pneumatic Diaphragm Pumps
PS25/PPPPP/TWS/TF/PTF 00-10181 AODD Pump, Polypropylene, 1/4" Pro-Flo® SHIFT, Bolted, Threaded, w/ PTFE
Model: PS25/PPPPP/TWS/TF/PTF
PS25/PPPPP/TWS/TF/PTF 00-10181 AODD Pump, Polypropylene, 1/4" Pro-Flo® SHIFT, Bolted, Threaded, w/ PTFE The Wilden® 00-10181-R, a 0.25" Pro-Flo® SHIFT bolted AODD pump built from Polypropylene with PTFE|Santoprene® diaphragms and PTFE ball valves, delivers up to 5.7 GPM at 120 PSI across fluid transfer systems.
TECHNICAL DATA
Specifications, performance and construction
Confirm the final operating point, materials, motor and connection standard before ordering.
PS25/PPPPP/TWS/TF/PTF 00-10181 AODD Pump, Polypropylene, 1/4" Pro-Flo® SHIFT, Bolted, Threaded, w/ PTFE
The Wilden® 00-10181-R, a 0.25" Pro-Flo® SHIFT bolted AODD pump built from Polypropylene
with PTFE|Santoprene® diaphragms and PTFE ball valves, delivers up to 5.7 GPM at 120 PSI across
fluid transfer systems. The traditional full-stroke diaphragm design ensures capability and longevity
in slurry, abrasive, or viscous applications (up to 125000 cP). Configured with threaded NPT side-right
inlet and threaded NPT side-right discharge, fits seamlessly into different process systems across many sectors. CE|UKCA certified.
AODD Pump, Polypropylene, 1/4" Pro-Flo® SHIFT, Bolted, Threaded, w/ PTFE
Item: 00-10181-R
Description: PS25/PPPPP/TWS/TF/PTF
Key Specifications
discharge orientation: side right
inlet orientation: side right
default max diameter solids (in.): 0.06
discharge size (in.): 0.25
inlet size (in.): 0.25
max flow rate (gpm): 5.7
max diameter solids (in.): 0.06
Attributes
Model (in.):
0.25
Technical Construction:
BOLTED
Wetted Path Material:
POLYPROPYLENE
Diaphragm Material:
PTFE
Diaphragm Design:
TRADITIONAL
Diaphragm Stroke:
Full-Stroke
Connection Standard:
NPT
Inlet Size (in.):
0.25
Inlet Orientation:
SIDE RIGHT
Discharge Size (in.):
0.25
Discharge Orientation:
SIDE RIGHT
Outer Piston Materials:
POLYPROPYLENE
Air Side Material:
POLYPROPYLENE
Valve Material:
PTFE
Valve Type:
VALVE BALL
Valve Seat MATERIAL:
POLYPROPYLENE
O Rings Gasket Material:
PTFE
Hardware Material:
STAINLESS STEEL
Muffler Material:
Plastic
Self Priming:
YES
Power Source:
COMPRESSED AIR
Air Inlet Connection:
0.25" FNPT
Maximum Allowable Operating Pressure (psig):
120.0
Max Air Pressure (psig):
120.0
Max Diameter Solids (in.):
0.06
Max Flow Rate (gpm):
5.7
Flow Rate 40 Psi (gpm):
4.2
Flow Rate 50 Psi (gpm):
3.6
Flow Rate 60 Psi (gpm):
3.0
Flow Rate 70 Psi (gpm):
2.2
Flow Rate 80 Psi (gpm):
1.7
Flow Rate 90 Psi (gpm):
1.2
Flow Rate 100 Psi (gpm):
0.7
Flow Rate 120 Psi (gpm):
0.0
Max Suction Lift Dry (ft.):
14.0
Max Operating Temperature (°F):
175.0
Min Operating Temperature (°F):
40.0
Max Viscosity (cP):
125000
Max Air Consumption (psi):
7.0
Atex Rated:
NO
CE:
YES
UKCA:
YES
FDA:
NO
3A:
NO
EHEDGE:
NO
UL:
NO
CSA:
NO
Shipping Weight (lbs):
4
