Reference image. Final construction follows the confirmed model and quotation.
Sewage Pumps
XBC Self-Priming Sewage Pump
Model: XBC
XBC Self-Priming Sewage Pump is designed for tank unloading, drainage, irrigation and industrial liquid transfer. DFIN Pump provides model verification, material selection and technical support based on the actual duty point.
TECHNICAL DATA
Specifications, performance and construction
Confirm the final operating point, materials, motor and connection standard before ordering.
Product Overview
XBC Self-Priming Sewage Pump is an industrial self-priming pump selected for tank unloading, drainage, irrigation and industrial liquid transfer. The final configuration should be verified against the actual liquid, duty point, temperature, installation and power supply.
Typical Applications
Tank unloading, drainage, irrigation and industrial liquid transfer.
Design Features
- Self-priming operation
- Simple pipework arrangement
- Easy inspection and maintenance
- Model and material selection supported by DFIN Pump engineers
Extracted Operating Data
- 1、 ≤45℃， ≤60℃
Values are reference data from the authorized source catalog. Confirm the selected model before ordering.
Technical Performance Data
|
Model |
Flow |
Head |
Power |
Efficiency |
NPSHr |
|
XBC25-8-15 |
8 |
15 |
2.2 |
45 |
2.0 |
|
XBC32-5-20 |
5 |
20 |
2.2 |
45 |
2.5 |
|
XBC32-10-20 |
10 |
20 |
2.2 |
45 |
2.5 |
|
XBC32-9-30 |
9 |
30 |
3 |
48 |
2.5 |
|
XBC40-10-20 |
10 |
20 |
2.2 |
45 |
2.5 |
|
XBC40-20-15 |
20 |
15 |
2.2 |
45 |
2.5 |
|
XBC40-15-30 |
15 |
30 |
3 |
48 |
2.5 |
|
XBC50-10-20 |
10 |
20 |
2.2 |
45 |
2.5 |
|
XBC50-20-12 |
20 |
12 |
2.2 |
45 |
2.5 |
|
XBC50-15-30 |
15 |
30 |
3 |
48 |
2.5 |
|
XBC50-20-35 |
20 |
35 |
5.5 |
48 |
2.5 |
|
XBC65-30-18 |
30 |
18 |
4 |
45 |
2.5 |
|
XBC65-25-30 |
25 |
30 |
5.5 |
50 |
3.0 |
|
XBC65-25-40 |
25 |
40 |
7.5 |
50 |
3.0 |
|
XBC65-40-25 |
40 |
25 |
7.5 |
50 |
3.0 |
|
XBC65-65-25 |
65 |
25 |
7.5 |
52 |
3.0 |
|
XBC80-40-16 |
40 |
16 |
4 |
50 |
3.0 |
|
XBC80-40-25 |
40 |
25 |
7.5 |
50 |
3.0 |
|
XBC80-25-40 |
25 |
40 |
7.5 |
50 |
3.0 |
|
XBC80-65-25 |
65 |
25 |
7.5 |
52 |
3.0 |
|
XBC80-80-35 |
80 |
35 |
15 |
45 |
3.0 |
|
XBC80-40-50 |
40 |
50 |
18.5 |
50 |
3.0 |
|
XBC80-50-60 |
50 |
60 |
22 |
55 |
3.0 |
|
XBC100-100-15 |
100 |
15 |
7.5 |
50 |
4.0 |
|
XBC100-80-20 |
80 |
20 |
7.5 |
53 |
4.0 |
|
XBC100-100-20 |
100 |
20 |
11 |
53 |
4.0 |
|
XBC100-100-30 |
100 |
30 |
22 |
53 |
4.0 |
|
XBC100-80-45 |
80 |
45 |
30 |
55 |
4.0 |
|
XBC100-80-60 |
80 |
60 |
37 |
53 |
4.0 |
|
XBC100-80-80 |
80 |
80 |
45 |
50 |
4.0 |
|
XBC125-120-20 |
120 |
20 |
15 |
55 |
4.5 |
|
XBC150-180-14 |
180 |
14 |
15 |
60 |
5.0 |
|
XBC150-180-20 |
180 |
20 |
22 |
60 |
5.0 |
|
XBC150-180-30 |
180 |
30 |
37 |
65 |
5.0 |
|
XBC150-180-38 |
180 |
38 |
55 |
45 |
5.0 |
|
XBC200-280-14 |
280 |
14 |
22 |
65 |
5.0 |
|
XBC200-280-20 |
280 |
20 |
37 |
62 |
5.0 |
|
XBC200-300-25 |
300 |
25 |
45 |
59 |
5.0 |
|
XBC200-280-28 |
280 |
28 |
55 |
55 |
4.8 |
|
XBC250-420-20 |
420 |
20 |
55 |
61 |
6.0 |
|
XBC300-800-14 |
800 |
14 |
55 |
65 |
6.0 |
|
Name |
quantity |
Notes(brand) |
|
diesel engine |
1set |
Shanghai Diesel Engine Co., Ltd. |
|
Self-priming sewage pump |
1set |
Zhejiang Yangzijiang Pump Industry Co., Ltd. |
|
Cooling fan water tank |
1 set | |
|
Special flexible connector |
1 payment |
HL3 |
|
Common channel steel base for pump unit |
1 set |
No. 14 |
|
car fuel tank |
1 |
60L |
|
Apollo storage battery |
2 |
12V-100A |
|
exhaust muffler |
1 stick |
|
|
Diesel engine control cabinet |
1set |
Sped, oil pressure, voltage, water temperature, vehicle overload alerts, start and stop, emergency parking, failure alarms, etc. |
|
Yellow rainproof cabinet |
1 |
Cover the engine and open the second door |
|
four wheel mobile trailer |
1 car |
Car pneumatic tires, traction bars, steering mechanisms |
| Pump set parameters | |
| Model: | YZJZW250-420-24 |
| Manufacturer: | Zhejiang Yangzijiang Pump Industry Co., Ltd. |
| In and out Port Size: | 250mm/200mm |
| Flow： | 420M3/h |
| Head： | 24M |
| Supporting diesel engine Power: | 64.7KW |
| Inlet direction: | Horizontal water ingress |
| Outlet direction: | vertically upward |
| Connection method: | Inlet\Outlet flange type. |
| Pump form: | Self-priming pump |
| Altitude requirements: | ≤1000m |
| Sealing form: | Alloy mechanical seal |
| Fuel tank capacity: | 60L |
| Control module/electrical appliance brand: | Zhengzhou Zhongzhi Technology Co., Ltd./Chint Electrical Appliances |
| Base channel steel grade: | 14# |
| Battery capacity: | 24V-100A |
| Pump flow parts Material: | Cast IronHT200 |
| Pump connection method: | Pin coupling |
| Diesel engine heating system: | none |
| Bearing brand: | SKF |
Selection Information Required
Please provide medium, concentration, flow, total head or pressure, temperature, viscosity or solids, voltage, frequency and installation method. DFIN Pump will confirm the suitable model and materials.
Catalog reference: authorized YZJ product data · Model XBC
